C-Series graphics cards for multiple displays and videowalls, Mura MPX video controllers and H.264 Maevex AV-over IP encoders/decoders are being presented at ISE 2015 by Matrox Graphics. Live demonstrations with Advantech can also be seen, Bilfinger Mauell, Scala and VuWall.

Matrox ISE 2015

Matrox Graphics and Matrox Video are in Ise 2015 Sharing stand (11-F68) and showcasing its latest graphics and digital video solutions. The first is showcasing the cards for multiple screens C-Series, Mura MPX controllers and Maevex AV-over IP encoders/decoders.

Matrox C420 for digital signage

For its part, Matrox Video has come with its solution for transmission and recording of video Monarch HD, and VS4Recorder Pro multi-camera recording app.

Matrox solutions can also be seen in live demonstrations they are performing. Advantech, Bilfinger Mauell, Scala and VuWall.

Graphics Solutions

Matrox Graphics C680Designed for the configuration of videowalls in digital signage applications, control rooms, safety, AV and embedded systems, C-Series graphics cards deliver optimal video performance, advanced multi-screen capabilities and EDID management through intuitive software to simplify display mounting, both vertically and horizontally.

This line, composed of models C680 and C240, Integrate 2 GB of memory and mini Display Port connectivity. The Matrox C680 card supports up to six 4K/UHD displays and more can be installed by inserting two C680s into one system. The framelock plate to board feature ensures synchronization of all screens to reduce cuts in the videowall and digital video.

Matrox C420 for Control RoomsFor its part, The Matrox C420 is especially suitable for the installation of digital signage systems in small spaces. Offers high speed with passive cooling, Reliability and quiet operation.

Especially suitable for AV integrators, System developers and manufacturers who want to have a videowall capture and display controller with a maximum of 56 inputs and outputs, Matrox Mura MPX cards redefine the future of video wall array management solutions.

Estas tarjetas proporcionan un alto rendimiento, Image quality, escalabilidad y conmutación, compatibles con canales de entrada universal para señales de vídeo tanto digital como analógico. PCIe x16 Gen2 bus architecture enables bandwidth maintenance and load balancing essential for large-scale multichannel projects. HD image capture and uncompressed data display ensure impeccable text quality, Video and graphics.

Matrox Maevex H264 Encoder DecoderMatrox también está exhibiendo en su stand la serie de codificadores/decodificadores Maevex 5100, la solución de distribución de vídeo por IP que permite ampliar o grabar hasta 1.080p60 de vídeo y audio a través de una red estándar, with a low user-defined transmission rate, with minimal bandwidth consumption.

Maevex Series 5100 allows the extension of Full HD video over standard IP networks for digital signage projects, as well as video collaboration systems, Automation and process control. It also allows software-based decoding on non-Maevex devices. Includes Matrox PowerStream software, that allows remote management of Maevex devices, and a wide variety of stream-management resources including unicast and network multicast.

Grabación y streaming de vídeo

Matrox Monarch HDMatrox Monarch HD es un pequeño codificador H.264 diseñado para productores de vídeo profesionales que necesitan transmitir un evento en vivo y grabar simultáneamente una versión de calidad del máster para la edición posterior al evento. A partir de cualquier fuente de entrada HDMI, como una cámara o switcher, Matrox Monarch HD genera un flujo codificado H.264, compatible con el protocolo RTSP o RTMP.

Mientras que codifica el vídeo a velocidades de bits adecuados para el streaming en directo, Matrox Monarch HD graba de forma simultánea un archivo MP4 de alta calidad o MOV en una tarjeta SD, USB or a mapped network drive.

Matrox VS4Recorder ProVS4Recorder Pro software enables high-quality recording of four live audio/video sources with a Matrox VS4 Quad HD-SDI card. This is ideal for recording live multi-camera productions, such as concerts and sporting events, and create video content that can be easily reused and archived.

VS4Recorder Pro offers two recording modes: multi-camera, that performs accurate and synchronized captures, and independent, allows you to choose from a wide selection of video and audio codecs. In addition, simultaneously provides a complete multi-view experience.

Scala at ISE 2015

Live demonstrations

Matrox solutions can also be viewed live with Advantech demonstrations, Bilfinger Mauell, Scala and VuWall.

Las tarjetas gráficas multipantalla Matrox C-Series son utilizadas con el software de señalización digital de Scala para reproducir contenidos desarrollados por Pixel Inspiration.

For its part, las tarjetas controladoras de pantallas de vídeo Matrox Mura MPX se han incorporado a las soluciones de Advantech y VuWall para crear una variedad de configuraciones de videowallas. Y los codificadores H-264 Matrox Maevex 5100 Series son utilizadas por Bilfinger Mauell y VuWall para codificar vídeo sobre IP en la entrega de vídeo de sus sistemas de controlador de videowall. Los productos Matrox también pueden verse en el stand del fabricante (11-F68).

Matrox PowerdeskAdvantech is performing at ISE a live demonstration of its AVS-540 videowall controller managed by VuWall software. The AVS-540 is a controller designed for 4U rackmount powered by the Xeon E5-2600 processor. This device can support five Mura MPX cards, allowing a maximum of twenty video source inputs and display outputs corresponding to twenty monitors.

The visualization software VuWall drives digital signage collaboration applications on a videowall of 3×3 with Matrox Mura MPX cards. VuWall software leverages the Mura Network API to provide a tool for scheduling and managing simple transitions and an intuitive scripting tool that allows users to create complex and dynamic scenes.. Matrox Maevex AV-over-IP encoders are used to transmit Full HD 1080p60 video at low bandwidth on an IP network for display on videowall.

Scala software is being used at the Amsterdam fair to play content developed by Pixel Inspiration on a digital signage videowall of 2×3 running on a Matrox C680 graphics card. Scala solutions increase sales, Improve brand loyalty and optimize customer experience.

Bilfinger Mauell's ME MultiView X Omnium software manages the monitoring and operation of display systems in control rooms, Network Operation Centers and Data Centers. Capture diverse sources, including applications, Desks, cameras and graphics signals directly from sources such as PCs and DVRs over an IP network.
