Displax Skin Ultra: One hundred touch tactile films for digital signage

Displax Skin Ultra touch foils, distributed by Macroservice, They are available in sizes 40 a 55 inches with widescreen image format 16:9. They are characterized by their flexibility to integrate into designs with curved shapes and their resistance., by operating through a glass that does not deform over time.

Macroservice has unveiled the range of tactile films Displax Skin Ultra, that are distinguished by offering optical transparency, multitouch functionality, response speed 5 ms, high resolution to work with 4K UHD displays and XTR Shield Plus technology for filtering and noise reduction.

In addition to detecting up to one hundred simultaneous and independent touches, These Displax sheets have the Palm function & Arm Rejection that recognizes the presence of the palm of the hand or arm, even when no touch is performed.

Available in sizes ranging from 40 a 55 inches, with widescreen image format 16:9, Displax Skin Ultra sheets are ideal for interactive digital signage and shop windows, indoor and outdoor information points and kiosks, touch tables and mega-tablets.

ProCap Foil Technology

Displax Skin Ultra sheets with projected capacitive touch technology (ProCap Foil) They are characterized by their flexibility to facilitate integration into innovative designs with curved shapes and durability by operating through a glass resistant to liquids and ultraviolet rays that does not deform over time..

ProCap touch technology (projected capacitive) Its operation is based on dividing the screen into different cells using ultra-fine conductive threads. (~0.010mm diameter) which are installed through the touch foil, vertically and horizontally.

These threads, which are almost invisible when the monitor is on, They connect to a controller and, later, a frequency oscillation is established for each thread.
When you touch the glass, a change is created in the frequency of the threads and at a specific point X-Y. The controller, so, calculate and identify the coordinate.

Configuration and installation

The new models are based on a transparent vinyl sheet (Foil) which is placed at any point on the inside of the laminated or tempered glass with up to 4 mm thick and the degree of vandalism required.

Once the Foil is located, all that remains is to superimpose a monitor or projection behind it and the installation is ready for any user to manage the multimedia application through the glass.. If a video projector is used, It is necessary to mount an optional translucent sheet that acts as a projection screen.

Skin Ultra touch films are only available in the permanent version. Each sheet receives a layer of optically transparent acrylic adhesive during manufacturing. Later, the installation process has arrived, the touch foil can be repositioned, but once assembled and dried it cannot be reused in case of uninstallation.
