This family comprises four models designed with processors ranging from Celeron Low Power Intel i7 is designed for use in vertical markets where stability, durability and quiet operation are required.

Shuttle DS77

Shuttle He has presented the series of mini PCs, fanless DS77 without comprising four models with processors soldiers, ranging from low-power Celeron Intel i7 to the fan.

Shuttle DS77As successors of the DS67 series, the DS77U, DS77U3, DS77U5 and DS77U7 teams join the product family PC 1 liter, joined in the category XPC slim.

The basic model is the DS77U and supplied as barebone by default, as the other three models. Box, motherboard, cooling system and power source are included in the pack as central components.

The system operates with an Intel Celeron processor 3865U two cores (2 x 1.8 GHz) which is integrated. 14 nm architecture and power consumption of 8 watts in standby mode ensures low power consumption but high performance.

The DS77U occurs fanless works almost completely silent; besides, it requires little maintenance, as little dust enters inside thanks to the passive cooling.
The DS77 series is also suitable for continuous operation whenever units intended to also have this continuously.

Shuttle DS77By loosening the two screws of the two covers robust steel case, fit one unit 2.5 "as hard or SSD and two SO-DIMM sockets that can hold up to 32GB of DDR4 memory. It also has a slot 2280 M.2 for quick NVMe memory cards, and a second module equipped with a WLAN M.2.

Con unas dimensiones de 20×3,95×16,5 cm, el DS77U presenta detrás dos interfaces Gigabit Ethernet de Intel, además de dos puertos USB 2.0, un DisplayPort 1.2, dos HDMI 1.4b y conexiones de audio. En la parte trasera también hay una conexión de varios pines con la que se puede iniciar el equipo de forma remota, como por ejemplo, en caso de montaje de difícil acceso. La oferta de conexiones se completa delante con un lector de tarjetas, dos USB 2.0 y dos USB 3.0, y dos puertos RS-232. Windows 10 (64 bits) y Linux serían los sistemas operativos apropiados.

Shuttle DS77“Con los modelos DS77, la familia de productos incorpora por primera vez modelos sin ventilador que soportan hasta tres pantallas de alta resolución. La reproducción de medios 4K se realiza a través de DisplayPort a 60 Hz, y de HDMI a 30 Hz. Dirigimos claramente la serie DS77 hacia los mercados verticales, donde se requieren sobre todo competencias como la estabilidad, la durabilidad y el funcionamiento silencioso”, explica Tom Seiffert, director de marketing y RR. PP. de Shuttle Computer Handels.

The position of use is also flexible, and computers can be provided with standing or mounted on any suitable surface and VESA support, also included in the scope of supply media screens.
